FLEXOR RIG - 固井高压水泥软管

FLEXOR RIG - 固井高压水泥软管

Tube: cement, oil and drilling mud resistant synthetic rubber
Reinforcement: six high tensile steel spirals.
Cover: special "Supertuff" cover for excellent abrasion resistance and long service life in heavy duty applications
Application: high pressure cement slurry transfer between pump manifold and cementing head
Temperature:-20 °C +121 °C(-4 F +250 °F)
Length: 61 m (200 ft) max
Notes: fully API 7K approved when supplied with Alfagomma Integral 2" 1502 Hammer Union couplings. Also available with API threaded male extra-long hexagon fittings


内胶层：耐油（包括可耐生物降解液压油）合成橡胶
加强层：四层/六层高强度钢丝缠绕
外胶层：耐磨损、耐臭氧、耐烃类化合物的合成橡胶
应用：高压液压管线。也适用于输送燃油、防冻液、空气和水。特殊的紧凑型设计结构适用于要求弯曲半径小的作业场合。专为固井时高压水泥输送而设计
常规运行温度范围：-40℃~+121℃（-40°F~+250°F）
安全系数：2.25:1
长度：最长到61米（200英尺）
注：六层钢丝缠绕结构，可装配整体式的FIG.1502由壬或带超长六角的API外螺纹接头
