EF 326/327/328 饮料集散管

EF 326/327/328 饮料集散管

Construction
Core ：Thermoplastic Elastomer food quality and FDA approved
Reinforcement ：EF326 Single or double braid of synthetic fiber
                            EF327 Single braid of steel wire
                            EF328 Single braid of aramid fiber
Cover ：Polyurethane, Black Colour, Pin Pricked
Application ：High pressure beverage dispensing lines 210 to 420 bar Specifically designed for gases, also gas mixtures used in fixed and mobile beverage dispensing units.Special tube material flavour free eliminates contamination risks and conforms to FDA and EC regulations. Please contact for different dimensions and working pressure
Note：Grey Colour Cover also available

结构：
内层：食品级FDA热塑性材料
加强层：EF326 单层编织聚酯纤维。
              EF327 单层编织钢丝。
              EF328 单层编织芳纶纤维。
外层：黑色，针扎-聚氨酯。用两条或多条不同尺寸的管线组成。特殊颜色及印刷要求请咨询
应用：高压饮料集散管路，集散介质有碳酸-(CO2)、氮(N2)或混合气体。
温度范围：-40℃ ～ 100℃（介质是空气和水时，温度不超过 70℃）
