727AA 钻井废弃物货油软管 – 硬壁 15 bar (225 psi) - 抗拉强度 26.000 kg

727AA 钻井废弃物货油软管 – 硬壁 15 bar (225 psi) - 抗拉强度 26.000 kg

Tube: black conductive NR-abrasion resistant
Reinforcement: high tensile textile cords with embedded steel helix wire - boot straps
Cover: black conductive SBR/NR- abrasion and ozone resistant
Application: dumpline for drill cuttings containing sand, sea water and abrasive material.
Also suitable as cargo hose for barite transfer.
Specially designed for heavy duty applications where highest end load resistance is required.
Not to be used with oil based mud.
Temperature: -30°C +80°C（-22 °F+176 °F)

内胶层：黑色导电NR-耐磨损
加强层：高强度纤维线并嵌有螺旋钢丝-粘有抗拉胶带boot straps
外胶层：黑色导电SBR/NR一耐磨损、耐臭氧。
应用：钻井岩屑（包含砂岩、海水和磨料）的排放。也可作为货油软管输送重晶石。专为超级恶劣工况设计，具有目前最高的抗拉强度，不可用于输送油基泥浆。
安全系数：3:1
常规运行温度范围: -30°C +80°C（-22°F +176°F)
推荐接头：
请联系公司根据具体应用推荐根据需要可选择不锈钢材质的接头
