715AA 钻井平台补给管硬壁 -散装物料 20 bar (300 psi)

可选颜色

产地

715AA 钻井平台补给管硬壁 -散装物料 20 bar (300 psi)

Tube: black conductive NR - abrasion resistant.
Reinforcement: high tensile textile cords with embedded steel helix wire - antistatic wire.
Cover: black conductive CR- abrasion, ozone, hydrocarbon and fire resistant.
Application: bulk material, barite and dry cement transfer from supply vessels to offshore platforms.
Reserve buoyancy calculated according to GMPHOM 2009
standard. Tensile end load resistance:
ID 4" 7.000 kg
ID 5" 10.000 kg. Electrically continuous.
Also available in self floating version.
Temperature: -30 °C +80 °C (-22 °F +176 °F)

内胶层: 黑色导电NR – 耐磨损
加强层: 高强度纤维线并嵌有螺旋钢丝 – 防静电线
外胶层: 黑色导电CR – 耐磨损、耐臭氧、耐烃类化合物和耐火
应用: 将散装物料如土粉、重晶石和干粉水泥从平台补给船输送到海工平台
根据使用需要可定制自浮式结构，该自浮式软管的储备浮力计算依据为GMPHOM 2009标准。
抗拉强度:
ID 4" 7.000 kg
ID 5" 10.000 kg
软管总成可具备ABS船级社产品证书
常规运行温度范围: -30 °C +80 °C (-22 °F +176°F)
品牌字样：ALFAGOMMA -ITALY- T-715 10 BAR (150 PSI) BULK MATERIAL HARD WALL(omega) - RIG SUPPLY - DNV N° P-11130
